Mina Family

Minalloon

Minalloon is the group / multi-occupant inflatable mine rescue shelter. Its six-layer composite shell combines a fire-retardant anti-static (FRAS) polymer coating, a graphene-enhanced FRAS layer for durability and structural health monitoring, a Dyneema structural core for tensile and blast strength, a TPU self-curing liner that cures into a permanent airtight bladder, micro-encapsulated self-sealing polymer capsules that burst to seal punctures, and aerogel-enhanced polyurethane foam for thermal insulation. An Automated Inflation System uses dual verification — a pressure wave sensor plus a geophone — so inflation only fires when both a pressure drop and high-magnitude vibration are detected. Stage 1 inflates in 10–30 seconds with inert gas for immediate crush resistance; Stage 2 runs 1–2 hours to fully cure the TPU liner into a rigid seal. Inside, CO/CO2/O2 sensors pair with scrubbers and O2 generators, and a through-rock VLF/LF wireless beacon transmits GPS and status to the surface.

Project images

Six-layer adaptive composite shell1 / 5

Minaweb

Minaweb is the software and control side of the mine emergency system, split into two interfaces. The Control Panel, for mine safety personnel, is a dark industrial UI with login and site confirmation, a live sensor dashboard and a 3D GIS map where unit status is colour-coded (green = normal, flashing red = alert, solid red = worker escalation, blue = rescue confirmed). It triggers a looping siren on alert, auto-calculates a rescue route from the safety station to the incident, lets staff push a Rescue ETA of 1–4 hours to the worker, and shows a 4-hour historical sensor graph with a path elevation indicator. The Worker Feedback Screen is a high-contrast cyan-on-black "survival mode" UI showing live sensor readings, the confirmed rescue ETA, ESP32 battery level and signal strength, plus an AI chatbot for first-aid and operational guidance, messaging to the control panel, and two large buttons: "MEDICAL EMERGENCY / ESCALATE" and "I AM RESCUED".

Miniloon

Miniloon is the backpack-portable, single-occupant version of the same shelter technology — the identical six-layer composite shell, automated dual-verification inflation and life-support sensor array, compressed into a pack a single miner can carry and deploy in seconds.

Project images

Miniloon main model1 / 3
